136XL025 / Timing Belt type XL

Description: 136XL025 Standard inch Pitch Timing Belt
* Reference: 136XL025
* Length: 13.6 in Pitch Length
* Width: 0.25 in
* Number of teeth: 68
* Pitch: 0.20 in
* Total Height: 0.09 in
* Tooth Height: 0.05 in
* Weight: 0.01 lb
* Other specifications: Limited Oil resistant, Antistatic, Tolerance Stable
Recommended use:
The 136XL025 is reinforced with helically wound tensile cords that are specially engineered, twisted, heat and chemically set, polyester material. The 136XL025 body rubber compound is a highly engineered synthetic rubber compound, specially compounded for cool running, flexibility, crack resistance, and excellent bonding to the outer fabric and tensile cords. The 136XL025 belts exceed USA RMA published ratings levels and are designed to perform at the identical or higher level than all other major USA Manufacturer’s and OEM belts of the same type.
